●The compressor is a fully enclosed vortex compressor.
●The entire system design is soft-started, step-by-step start-up, to avoid excessive start-up current and impact.
●The electric vehicle air conditioner has an aluminum alloy bottom, with glass steel covers on both sides, and elegant flow lines. The air-conditioning structure is compact and reasonable. light-weighted with small size, high cold-to-weight ratio, which is the lightest electric vehicle air conditioner in the same specification
●High energy efficiency. Refrigeration and heating double efficiency
●The fan adopts a safe voltage of 24V DC. According to the users choice of brushless or brush fans, it is lightweight, safe and reliable. Fan adopts modular control, stepless speed regulation to ensure the comfort of the car
●The two devices are arranged in parallel and use high-efficiency heat-exchanged internal ribbed tubes. The condenser adopts a small diameter of 7. The process is designed to reduce the diameter and supercooling. to strengthen the heat transfer of the condenser and reduce the power consumption of the system compressor
●Electric vehicle air-conditioning working environment temperature-10C~-55C with excellent heating performance in a low temperature environment
●With multi-level insulation and shock absorption measures, the insulation level reaches Class and all high-voltage live parts and housings are tested for withstand voltage: >3500V Ac can effectively prevent electric shock hazards
●It's equipped with good protection function. Overvoltage, overcurrent, overheating. Overload，underphase, undervoltage, and protection functions; the system is also equipped with pressure protection
●Protection class: IP55. which can meet the requirements of all kinds of environments for all weather work
●In the entire system design, in order to ensure the reliable operation of electrical components, a shield structure with auxiliary cooling, protection, and suppression of interference(EMC) is set up. All weather work can be waterproof, moisture-proof, dust-proof, anti-corrosion with strong anti-electromagnetic interference
●Smooth operation, low vibration, low noise
The entire control adopts intelligent microcomputer control, sharing data with the whole vehicle through the CAN bus, which is beneficial to the judgment of maintenance and can realize the remote control function at the same time
●Good electromagnetic compatibility
● The entire air-conditioning structure is simple, and the door covers on both sides are reasonably arranged and easy to maintain
